XLPE N Clad

Aerofoam® XLPE N Clad system contains sheets, rolls, tubes and tapes. Insulation foam is made of  closed cell cross-linked polyolefin coated with a strong and durable jacketing which replaces costly and complex aluminum, zinc plated steel or stainless-steel sheet facings. The foam has excellent properties in terms of condensation control, mechanical and chemical resistance, and long term thermal block. Aerofoam® XLPE N Clad sheets, rolls, tubes and tapes have a very good dimensional stability, demonstrating ‘memory effect’ (they tend to come to their original shape after being compressed). Aerofoam® XLPE N Clad sheets, rolls, tubes and tapes are an economical solution compared to the expensive and labor intensive aluminum, zinc plated steel or stainless-steel cladding. Some of the benefits are the following: less skilled labor required, fast installation (50% faster than metal cladding), lightweight material, safe to use (N Clad jacketing – no safety equipment required), easy to cut, no drill required (light punching tool is enough), no power tools required, easy and light to lift and carry. Aerofoam® XLPE N Clad jackets can be cut on-site without waste (on a cutting table) and space-saving storage.
Aerofaom N Clad Rolls and Sheets x

In order to install Aerofoam® XLPE N Clad in a professional manner, please drop an email at enquiry@rhira.com to receive the installation handbook.

APPLICATIONS

  • Indoor and outdoor pipe, air ducts and tanks
  • Industrial pipelines (Chemical, Pharmaceutical, Oil and Gas, Food and Beverages)
nclad x
Aerofoam N Clad Rolls x

PROPERTIES

 UV and corrosion resistance
 Fire rated “CLASS O” as per BS 476 Parts 6 & 7
 Very low water vapor permeance (perms)   <5.1 x 10-10 g/Pa.m2.s
 Water and water vapor resistant
 Very low water absorption rate (0.0023 g/m2)
 High thermal efficiency (λ[W/(m•k)]    0.036
   (24 °C)
 Wide temperature range (from -80 °C to +105 °C)
 Antibacterial & antifungal
 Environmental friendly – ODP = 0 and GWP < 5
 Very low VOC emission level ( <4 µg/m2/hr)

FEATURES

  • Excellent thermal efficiency
  • Weather resistant
  • Resistant to salt spray
  • Resistant to mold growth
  • Environmental friendly foam
  • High mechanical strength and durability
  • UV Resistant
  • Chemical resistant
  • Resistant to bacteria
  • Ozone resistant

REQUIRED ACCESSORIES

  • Aerofoam® Glue
  • Aerofoam® N Clad Tape
